Computer Networks 52 (2008) 2677–2689
Contents lists available at ScienceDirect
Computer Networks journal homepage: www.elsevier.com/locate/comnet
A stratified traffic sampling methodology for seeing the big picture Stênio Fernandes a,c, Carlos Kamienski a,b, Judith Kelner a, Dênio Mariz d, Djamel Sadok a,* a
Universidade Federal de Pernambuco, Centro de Informatica, Cidade Universitaria, 50732-970 Recife, PE, Brazil Universidade Federal do ABC, Santo André, SP, Brazil Centro Federal de Educação Tecnológica de Alagoas, Maceió, AL, Brazil d ´ba, João Pessoa, PB, Brazil Centro Federal de Educação Tecnológica da Paraı b c
a r t i c l e
i n f o
Article history: Received 25 September 2006 Received in revised form 8 April 2008 Accepted 16 May 2008 Available online 5 June 2008 Responsible Editor: S. Kasera Keywords: Traffic sampling Measurement Traffic engineering
a b s t r a c t This work explores the use of statistical techniques, namely stratified sampling and cluster analysis, as powerful tools for deriving traffic properties at the flow level. Our results show that the adequate selection of samples leads to significant improvements allowing further important statistical analysis. Although stratified sampling is a well-known technique, the way we classify the data prior to sampling is innovative and deserves special attention. We evaluate two partitioning clustering methods, namely clustering large applications (CLARA) and K-means, and validate their outcomes by using them as thresholds for stratified sampling. We show that using flow sizes to divide the population we can obtain accurate estimates for both size and flow durations. The presented sampling and clustering classification techniques achieve data reduction levels higher than that of existing methods, on the order of 0.1% while maintaining good accuracy for the estimates of the sum, mean and variance for both flow duration and sizes. Ó 2008 Elsevier B.V. All rights reserved.
1. Introduction Traffic monitoring is seen as an important tool for engineering networks of varying sizes [21]. Characterizing and understanding the traffic mix enables Internet Service Providers (ISPs) to devise new business and settlement models. Recently, the pie has been shifting from transport to content services and understandably many sought a piece of the new opportunities. Efficient measurement strategies became an essential tool contributing to a number of tasks some of which were unforeseen until today. Traffic measurement has been used for identifying anomalous behavior (such as unexpected high traffic volumes due to denial of service attacks, routing problems, etc.), for designing and validating new traffic models, for adequate planning of seasonal activities, such as upgrading network capacity,
* Corresponding author. Tel./fax: +55 81 2126 8954. E-mail addresses: [email protected] (S. Fernandes), [email protected] (C. Kamienski), [email protected] (J. Kelner), [email protected] (D. Mariz), [email protected] (D. Sadok). 1389-1286/$ - see front matter Ó 2008 Elsevier B.V. All rights reserved. doi:10.1016/j.comnet.2008.05.011
which allows introducing new services or the adoption of usage-based and content-based pricing. Commonly used flow monitoring tools (such as Cisco’s NetFlow [2] and Juniper’s JFlow [17]) and packet level capture tools suffer from lack of scalability relative to link capacity. Monitoring high-speed links, such as OC-48 and OC-192 yields huge data volumes. Currently both CPU and storage capacities remain limiting factors. As link capacity and the number of flows grow, maintaining individual counters for each individual flow traversing a router becomes computationally and/or economically cumbersome to keep up with [1,5,6]. In order to address this issue, sampling has been used a proven statistical strategy for dealing with high volumes of network traffic data [3]. It has the advantage of lowering the processing cost, the storage and hardware requirements in a network monitoring infrastructure. Like a quality control engineer, a network engineer needs to collect data at diverse time frames and places. Therefore, to make this process faster as well as accurate, one should rely on analyzing only a small, although relevant, subset of the network traffic data. This sample is then
2678
S. Fernandes et al. / Computer Networks 52 (2008) 2677–2689
Fig. 1. Traffic monitoring, flow classification and filtering.
analyzed and a statistical quality verdict is given. In other words, one only needs to observe a small part of the traffic to visualize the big picture. Fig. 1 shows how sampling can be used as a flow filter capable of selecting a representative set of flows only. By representative we mean those when selected, will give us an accurate view of the traffic mix. We show in this work that the classification strategy – also known as clustering – is primordial to achieve reduction of stored data but yet keeping its representativeness. Sampling may be applied during the capture (packet level) or after data summarization (flow level). Fig. 2 depicts the envisioned benefits of using sampling techniques for flow traffic data management. A typical scenario is made of a router that captures packets and builds flows, a collector that retrieves and stores flow records and an application with a Graphical User Interface (GUI) that generates reports out of the stored data. The numbers indicate the possible sources of improvements when deploying sampling techniques at different components of the network management apparatus. On-line sampling may be performed directly by routers at the time they are capturing packets and building flows, whereas off-line sampling is performed after flows are built by the router and transmitted to the flow collector. If off-line sampling is used, optimizations may be obtained in the reduced storage requirements for the collector (#3), reduced data communication from the collector to the reporting application (#4) and reduced memory and processing requirements at the reporting application (#5). On the other hand, if
on-line sampling is used, optimizations may be obtained at the reduced processing and memory requirements for the router (#1) and reduced data communication from the router to the collector (#2). The processing and memory requirements will certainly be reduced at the router, since they preserve all flows in memory until they are flushed to the collector and the memory is cleared. If sampling is deployed, the router may detect that a given flow does not need to be stored, so that the allocated memory space for that particular flow can be released and the processing work of the remaining flows will be performed faster. A variety of sampling strategies have been proposed recently for optimizing the packet selection process (for flow accounting) [18–20] and flow selection (for statistical analysis of the original traffic). Sampling techniques may be divided into systematic, random and stratified sampling [4,24]. The simplest sampling process is uniform 1/N sampling (a type of systematic sampling), where one of every N packets is retained. Although this technique has been largely used, e.g. by CISCO’s Netflow in low-speed links, it does not always present adequate results since it has been shown that IP flows usually have heavy-tailed distributions for packets and bytes [6]. In such a situation, the selected packets from the sampling process will be biased by the huge number of small packets and just a few will be selected from the tail, i.e., the bigger packets. Sampling may also be target dependent where for example only flows above a given size or duration are retained for charging purposes or selective of given services such as VoIP and
Fig. 2. Envisioned benefits of sampling.
S. Fernandes et al. / Computer Networks 52 (2008) 2677–2689
other P2P file sharing activities for content-based charging [7]. Some sampling strategies, however, rely on flow information as they account only for relatively large flows, also leading to a biased sampling process due to the unbalanced number of selected small flows (also known as ‘‘mices”) and bigger flows (also known as ‘‘elephants”) [25]. The main contribution of this work is the introduction of a new flow classification methodology which applies two well studied statistical techniques, namely stratified sampling and cluster analysis, in order to reduce the amount of collected traffic that is necessary for characterizing the traffic flows. The role of stratified sampling is the intelligent grouping of the elements of the population in a number of strata (a set of samples), according to a key information from each flow (e.g. flow size) and in such a way that each stratum contains only flows with certain characteristics or limits (e.g. flow size greater than 500 bytes and lesser than 1000 bytes). For the traffic analysis, the samples are then taken from each subset or stratum, instead from the original population. We show that if we do our flow classification right, then important gains are achieved, as discussed later in this paper. There may be different ways of classifying flows into groups and in this paper we present the results for two different approaches. Our first approach consists on defining the limits of the strata manually, according to an empirical observation. However, since the limits between strata have a significant importance for stratified sampling and the traffic profile keeps changing in the future [22], it becomes important to automate this step rather than relying on human knowledge. Then, we turn to investigating the effects of finding these limits automatically by using cluster analysis techniques. We show the effectiveness of using stratified sampling and cluster analysis as a tool for describing traffic behavior at a flow level. The measurement process is reduced to the capture and storage of only a small fraction of the original number of flows. Compared to existing methods, our proposed stratified sampling and flow classification methodology achieves higher reduction levels on the sample size with good accuracy in the estimates for the sum, mean and variance for flow duration and flow size. The remainder of this paper is structured as follows: Section 2 reviews related work where sampling is used for traffic monitoring. In Section 3, we present the necessary background on stratified sampling and cluster analysis, which will be important to better understand the rest of the paper. Section 4 presents the data classification methodology we are proposing and also discusses the mechanism for evaluating its performance using real traces. Section 5 discusses the main results obtained and compares our strategy with another one, namely smart sampling. In Section 6, we discuss some choices that are involved in an actual deployment of stratified sampling for gathering traffic flow information. Finally, Section 7 concludes this work. 2. State of the art Packet and flow sampling have drawn a great deal of research in the attempt to estimate traffic profiles. Some works particularly focused on router packet sampling
2679
whereas others chose to define resources necessary for building the measurement infrastructures [10,11,13,18]. A close approach to ours is that of Duffield et al. [5,8]. The authors pointed to the use of size dependent sampling instead of uniform sampling. In what they called Smart or Threshold Sampling, an object of size x is selected according to a sampling probability function pz(x) = min{1, x/z}. Therefore, flows of size less than a threshold z are selected with probability x/z whereas flows with size equal to or greater than z are always selected. The authors showed that they could control the volume of samples and the variance of an estimator (e.g., sum of sampled sizes) by using threshold sampling. In a further study [9], they also presented an approach capable of inferring the probability distribution for the number and length of flows in the original Internet traffic. Their results are based on flow information built from a sampled set of packets. Honh and Veicht [15] looked at some theoretical results for the problem of recovering traffic statistics, higher than first moment order, using sampling. They named their approach, inverted sampling and applied it to both packet and flow filtering. The authors also defined three statistical information recovery levels within their model: the packet level dealt with the spectral density for packet arrival; the flow level examined per flow packet distribution; and finally an internal level to the flows that determined the packet arrival average rate for a given flow. They discovered that their sampling technique at the flow level provided excellent results even with thinning probabilities on the order of 1%. Amazingly, the Inverted Sampling technique could recover detailed characteristics of the raw data traffic such as its spectrum or the distribution of flow size. Under our proposed stratified sampling and flow classification methodology, we achieve even higher reduction levels, on the order of 0.1% with good accuracy in the estimates of the sum, mean and variance for flow duration and sizes. Estan and Varghese [11] proposed two scalable algorithms for identifying large (also known as elephant) flows, namely, Sample and Hold and Multistage Filters. Their sampling strategies only maintained records for large flows they called Elephants, hence reducing considerably the storage requirements. More importantly, Estan et al. [12] pointed out a number of limitations in the NetFlow architecture [1]. They particularly drew the attention to the maximum number of records that Netflow can classify and that a saturation level may quickly be reached when faced with a large burst of flows. A second NetFlow architectural problem is seen to be traffic congestion near the collector, a special server used as part of this architecture to collect all the sampled data. In addition, information loss on the path from a router to the collector can be extremely harmful to the analysis itself [10]. Finally, NetFlow’s sampling strategy is static and does not adapt to the sampled traffic [12]. Intuitively one would argue for the increase of the sampling rate when aggregate traffic is low to obtain a higher resolution of the traffic profile. On the other hand, this rate must be lowered when the monitored traffic increases to avoid overflow in the measurement architecture. To this respect, these authors also proposed a new dynamic rate sampling for NetFlow they named Adaptive NetFlow (ANF).
2680
S. Fernandes et al. / Computer Networks 52 (2008) 2677–2689
In a separate piece of work, Kompella and Estan [18] proposed a novel flow measurement architecture called Flow Slices. Their elegant solution combines features from previous research work such as threshold sampling [5], adaptive NetFlow [12] and sample and hold [11]. 3. Background 3.1. Stratified sampling Stratification has proven itself as a technique capable of leading to the discovery of a population’s statistical features by only looking a subset of it. That is, choosing only a few elements as a representative subset of the entire sample set. Under stratified sampling [4] a heterogeneous population is divided into isolated subpopulations that present certain level of homogeneity. It is also common to use some a priori knowledge to divide a population with N elements into N1, . . . , NL groups or strata. First, one should find the amount of the objects within each stratum is n1, . . . , nL, respectively. Next, a sample is selected from each stratum or subgroup. Stratified sampling can be classified into uniform, proportional (or Bowley), and optimal. The key step here is to determine the size of each stratum. Unlike the uniform stratification where all strata have the same size, proportional stratification maintains some proportionality among the number of elements in each stratum, whereas the optimal approach considers in addition to the stratum size the variability among its elements. We chose to use optimal stratified sampling without reposition of selected elements, meaning that each flow must be selected no more than once. Hence the strata are created according to both their size and variability. We assume a population with N elements to be divided into L strata. The aim here is to look for n elements that need to be sampled in order to determine a statistical characteristic, such as, the mean flow size or its mean duration. The sample size, n, should be calculated from: 2
nP
2
k AN 0002 k BðN 0002 1Þ e2 ðN
2
0002 1Þ þ k B
;
ð1Þ
where k is the quartile (1 0002 a) of the standard normal distribution and e is the precision error. The terms A and B are given by Eqs. (2) and (3), where Nh and rh are the number of elements and the standard deviation within a given stratum h, respectively
P 0002P 00032 N h r2 N h rh A¼ P h0002 P ; Nh Nh P Nh r2 B¼ P h: Nh
ð2Þ ð3Þ
Neyman [1] established a criterion for the distribution of the sample elements as long as they maintain a minimum variance within a stratum. It states that the number of elements within a given stratum, nh, considering a sample of size n, should be followed by:
Nh rh nh ¼ n P : N h rh
ð4Þ
3.2. Cluster analysis Cluster analysis (CA) refers to a number of methods for grouping similar objects into categories. In general, clustering techniques have been mainly used for statistical data analysis in several research fields, such as data mining, machine learning, etc. CA is an important step in our sampling methodology especially as we are seeking to extract traffic information from multivariables, that is, flows with size, duration and other attributes. The output of this technique is the basis that forms our a priori knowledge on traffic that stratified sampling is going to explore. Clustering can therefore be used to identify similarities between the analyzed flows and classify these into groups that are highly dissimilar from each other [14]. Such grouping not only depends on the data at hand but also on how good we formally define the similarity concept. This can mathematically be modeled as a distance between two objects. Please note that in multivariable clustering, one should always rely on normalization, which is a process to remove the effect of a variable into another to decrease its major influence on the distance metric. Also note that CA is also capable of identifying odd values as they tend to be exceptionally distant from most groups. A key element to the CA methodology is the adequate choice of the proximity concept definition. The literature is full of mathematical formulas expressing distances between multivariable objects. A general formulation is given by Minkowski [16]:
dp ðxi ; xj Þ ¼
d X
!1=p jxi;k 0002 xj;k jp
;
ð5Þ
k¼1
where d is the multivariable object dimension. The wellknown Euclidean and Manhattan distances are special cases of the Minkowski distance with p = 2 and p = 1, respectively. Once we have our distance defined, we need to establish the CA technique we are going to use. There is a wide range of CA algorithms available in the literature although no canonical classification. They do however differ according to the data being analyzed, the clustering criteria they use and also the mechanism they use to approach the solution including statistical, fuzzy logic and other strategies. Unlike other existing studies where clustering can be based on density, probabilistic, monothetic (decisive) or polithetic (open), we opted for a flexible clustering technique that can adopt a hierarchical or partitioned vision of the flows. In this work we examine two clustering techniques, namely, K-means and CLARA [16]. Both popular and simple, K-means offers a reasonably good clustering technique for our problem. We first look for k centroids or geometrical centers, one for each group. Next, K-means assigns each of the flows to the group of the nearest centroid using our previously defined Minkowski multivariable distance concept, with p = 2 (i.e., the Euclidean distance). Once done with all the flows, we need to review our initial decision by selecting new k centroids. This process is continued until the proposed k centroids stop changing and we have our k stable clusters. We need to say something regarding how K-means compares the
S. Fernandes et al. / Computer Networks 52 (2008) 2677–2689
effectiveness of a newly established cluster around a centroid with that previously obtained when using a different centroid. K-means uses a fitness test given by

k X n X
dj;p ;
ð6Þ
j¼1 i¼1i
where dj;p ¼ kxi 0002 cj kp is the distance metric between xi,j, a given element of group j, and cj, the centroid of group j. It gives us a measure of the distance of the n elements from their respective cluster centers. The second clustering method we look into is known as CLARA (Clustering LARge Applications), which is an improved implementation of PAM (Partitioning Around Medoids). PAM is considered a more robust version of K-means, as it minimizes the sum of dissimilarities instead of the sum of squared Euclidean distances. Also, PAM is used typically when we want to create clusters around typical objects (flows) known as medoids. Once we establish the medoids using iterative selection, all flows are then assigned to the group with the nearest medoid. PAM is O(n2) with asymptotic complexity to memory use turning it unsuitable as is for the clustering of large data sets. CLARA is a specially devised PAM to deal with this problem, as it exhibits a linear execution time and memory use characteristics, having time complexity O(n). CLARA uses mainly two single stages. First a sample of predefined length is retrieved from the data set and distributed over the k groups. Successive medoids are examined in an attempt to find the one with the shortest distance to flows from the sample in what is known as the build phase. Next, the most representative elements are swapped in order to lower the average distance between objects in a group. This second phase is known as the Swap phase. More details on both K-means and CLARA may be obtained from [16]. ðjÞ
4. Methodology This work analyzes four different flow traces shown in Table 1. These were obtained from the national Brazilian academic network (RNP) at PoP-PE over a 34 Mbps link between the 15th and 19th of September 2004. We used a packet capturing tool that fed a flow identification module, where a flow is seen as a set of packets with the same 5-tuple: source IP address, destination IP address, port numbers for origin and destination and protocol [23]. Core to our approach is the way flow data has been stratified. We show the importance of our methodology as it offers a 10-fold gain over existing works in some of the analyzed scenarios. Not only the use of stratifying is beneficial but similarly the way this is applied is of utmost
Table 1 Characteristics of the traces used in the analysis Name Trace Trace Trace Trace
Date #1 #2 #3 #4
September September September September
15, 17, 18, 19,
2004 2004 2004 2004
Time (h)
Volume (GB)
# Flows
08–12 08–12 14–18 14–18
28 38 24 63
7,013,744 7,497,991 4,086,476 6,571,586
2681
relevance. Clearly there are a number of ways we may think of when grouping the data. These include classifying flows according to their sizes, durations, transmission rates, etc. In choosing one of these schemes, it is then important to be able to obtain as much flow statistical information as possible. For example, classifying flows according to sizes should also provide us with information on flow durations. The statistics should not be seen as exclusive with flow classification criteria as this process is merely seen as a step leading to the manipulation of a smaller but yet representative data sets or population. We also show that the number of such data groups or strata is an important study factor. We propose a data classification methodology with the following seven steps: 1. Deciding which variables we need to observe – there is a wide range of flow attributes that are often interesting to monitor. Examples of these include number of packets, packet minimal/average/maximal sizes, transport and application protocol used, etc. Without loss of generality, we limited the variables monitored in this work to: (a) flow duration in seconds; and (b) flow size, defined as the amount of bytes in all the packets of a flow. Note that although we observed two distinct variables, only flow duration is presented as the stratifying variable, i.e. the variable used for classifying flows. Flow size was also tested as the stratifying variable when we considered manually established strata, as presented in Section 5.1, and the results were similar to flow duration. Therefore, since both variables perform adequately with clustering, for simplicity only flow duration is presented as the stratifying variable throughout the paper. 2. Grouping flows and setting up strata limits – this step refers to the process of finding out groups of flows related to each other and defining the upper limit of the stratifying variable (flow duration) for each strata. There may be different ways of classifying flows into groups and in this paper we present the results for two different approaches. Our first approach consists on defining the limits of the strata manually, with an exponential increase (e.g. 0.01 s, 0.1 s, 1 s, 10 s, 100 s, 1000 s, 10,000 s). This choice relies on an expert knowledge, i.e. an empirical observation that flows can be grouped into strata according to these limits. Our second approach investigates the effects of finding these limits automatically by using cluster analysis on a trace. Our goal is twofold. First, since the limits between strata have a significant importance for stratified sampling and the traffic profile keeps changing in the future, it becomes important to automate this step rather than relying on human knowledge. Second, intuitively we consider the possibility of improving the precision of the stratified sampling by choosing optimal limits between strata, aimed at finding sub-samples with less internal variability. In this work, we use both CLARA and K-means algorithms to identify meaningful groups according to flow duration thresholds. 3. Choosing the number of strata – the two approaches for grouping flows into strata (manual-based and clustering-based) require the prior knowledge of the number of strata to work with. Preliminary experiments showed that the use of more than 8 strata gives little gain in results
2682
S. Fernandes et al. / Computer Networks 52 (2008) 2677–2689
having the sub-sample for each stratum, compute sample flow size and duration using the estimator of the stratified sampling technique; (e) repeat this process 100 times and obtain the average flow size and duration for the sample. We used a 99% asymptotic confidence interval. 7. Comparing population and sample metrics – in order to find out whether a sample is representative of the population, the metrics of both must be compared. In other words, the average, sum and variance for flow duration and sizes of the samples must be a representative approximation of those of the population; otherwise the sample may not be used in place of the population. Although we observe the average, standard deviation and sum of flows durations and sizes, only average values are presented. In addition to the proposed stratified sampling methodology, both uniform and smart sampling [5] have also been compared.
5. Results 5.1. Results for stratified sampling Using the proposed stratified sampling technique we compare mean values for flow size and duration obtained for both the population and its samples. As an example, in Fig. 3 we compare the average of the samples for the mean of flow sizes with that of the original population. We have done this for each one of the four traffic traces.
4340 population sample
4330 4320 4310 4300 4290
Mean of flow size (bytes)
Mean of flow size (bytes)
accuracy while leading to higher processing overhead. Consequently, we limit the number of strata to 2, 4, 6 and 8. Indeed, our main interest is on finding the minimum number of strata that gives us acceptable results. 4. Establishing sample size – we obviously seek to use the lowest sample size capable of representing the original population of flows. We tested four sample sizes, namely, 0.01%, 0.1%, 1% and 10% of the original population size. Sample sizes smaller than 0.01% were considered inadequate, since results reveal that with this size the sample is not representative in most cases. Also, sample sizes larger than 10% were also not used, since the reduction is not significant. 5. Determining the number of elements per stratum: the number of elements varies for different scenarios and in our case needed to be computed for all traces (trace #1 to #4, as shown in Table 1), approaches to grouping elements (manual and automatic with CLARA and K-means), number of strata (2, 4, 6, 8) and sample sizes (0.01%, 0.1%, 1% and 10%). We use the Neyman method where the sample sizes are chosen proportional to the products of the standard deviations and the stratum sizes [1]. 6. Establishing the achieved accuracy – we adopted Monte Carlo Simulation as a validation tool to establish the accuracy achieved by each of scenarios considered in our work. This step works as follows: (a) consider the population of flows from a given trace; (b) separate the flows into each strata according to their limits; (c) for each stratum of the population, take randomly some elements to make up the stratum of the sample, based on step 5; (d)
4280
5440 5430 5420 5410 population sample
5400 5390
0.01%
0.1%
1%
10%
0.01%
0.1%
1%
Sample size
Sample size
(a) Trace #1
(b) Trace #2
10%
10240
6300 6290 6280 6270 6260 population sample
6250 6240
Mean of flow size (bytes)
Mean of flow size (bytes)
5450
10230 10220 10210 10200 10190 10180
population sample
10170 10160
0.01%
0.1%
1%
10%
0.01%
0.1%
1%
Sample size
Sample size
(c) Trace #3
(d) Trace #4
Fig. 3. Mean of flow size for different traces (using 8 strata).
10%
2683
S. Fernandes et al. / Computer Networks 52 (2008) 2677–2689
no practical insights for ISPs, although bearing a great statistical importance. Therefore, due to space constrains throughout this paper only Trace #1 will be used (our choice was random). Its population size is 7,013,744 flows, and consequently the number of flows is: 701, 7013, 70,137 and 701,374 flows for sample sizes of 0.01%, 0.1%, 1% and 10%, respectively. Furthermore, the vertical bars representing the confidence intervals will be omitted in most results henceforth, since they have equivalent dimensions for a variety of different days, sample sizes and number of strata. Fig. 4 shows results of both flow size and duration for Trace #1 while varying the number of strata used over different simulation experiments (in Fig. 3, only the results for 8 strata were shown). Three important observations can be made from Fig. 4. First, the use of a 0.01% sample size turns out to be insufficient, since its samples exhibit large variability as shown by both Fig. 4a and b. Second, more reliable results are obtained when the number of strata is at least six, as the confidence intervals become small and always include the population mean. On the other hand, the gain seen when using 8 strata instead of six is small, leading us to believe that no more than 8 strata are needed for most cases. Third, flow size and duration yielded similar results. 5.2. Finding automatic limits among the strata In this section we take a closer look at the CLARA and Kmeans clustering techniques in the effort to finding more adequate limits between the strata. For each technique, we ran the clustering algorithms with four different numbers of groups: 2, 4, 6 and 8. In a typical case, clustering algorithms are capable of finding the ‘‘ideal” number of groups on their own. Once we had the elements (flows) allocated to their groups, both lower and upper limits of each group were found. Table 2 presents the lower and upper limits yielded by CLARA and K-means when configured to work with two groups. Interestingly, we see that for both, the limits do not overlap for flow duration. For example, CLARA flows lasting less than 155 s were classified into group 1, whereas the others fell into group 2. Flow size limits overlap however between these two groups. For example, for
17.1 population 2 4 6 8
4520 4470 4420 4370 4320 4270 4220
Mean of flow duration (s)
Mean of flow volume (bytes)
Such comparison is important as it gives us a statistical guarantee for using a sample instead of the original population. As explained in Section 4, we first used some rule of thumb regarding knowledge of typical behavior of flow sizes and durations to set the limits between the strata. These results are presented in this section. In a second stage such limits were obtained automatically from the traces in an unsupervised manner, as we show in Section 5.2. Under the intuitive approach, the results for the mean of flow size for our four traces, four sample sizes (0.01%, 0.1%, 1% and 10%) and with 8 strata are depicted in Fig. 3. For the samples, we also plotted the vertical bars of the 99% asymptotic confidence intervals obtained from 100 replications. A graphical analysis shows that the larger the sample size is, the more precise is the confidence interval, i.e., its amplitude is smaller. The dotted line represents the actual real mean of the population computed separately for all the captured traces’ flows. It can be seen that the population mean falls within all the established confidence intervals. In other words, the intervals built from the samples are representative and the samples may be used instead of the original captured flow population for representing the mean of flow sizes. For instance, in Fig. 3a the mean flow size for the population is 4306.3 bytes and for a 1% sample size is 4308 with a ±2.1 byte confidence interval. This first result emphasizes the existing tradeoff between sample size and precision (including variability). On the one hand whenever a higher precision is needed, a larger sample size should be adopted, in order to ensure that any sample will be able to represent the population. On the other hand, if a lower precision is tolerated by a given analysis, then even sample sizes of 0.01% may be used while leading to lower requirements for the infrastructure in terms of processing, transmission and storage costs. From Fig. 3, we also see that the results obtained for all four traces present similar behavior. Such similarity shows up not only for the mean of flow size obtained from of a given number of strata, but also for the flow size sum and variance for all the strata. Sum and variance are not shown in our results, since the latter is similar to the mean (or more precisely, the estimator of the mean is directly derived from the estimator of the sum) and the former brings
17.0
16.9 population 2 4 6 8
16.8
16.7 0.01%
0.1%
1%
10%
0.01%
0.1%
1%
Sample size
Sample size
(a) Size
(b) Duration
Fig. 4. Mean of flow size and duration (Trace #1).
10%
2684
S. Fernandes et al. / Computer Networks 52 (2008) 2677–2689
flow records. In this paper, we limit ourselves to comparing clustering techniques with and without the automatic setup of such limits. We will use the term ‘‘expo” when referring to the results of the stratified sampling produced by manually specified exponential limits.
K-means the first group includes flows from 23 bytes to 115 MB and the second one those ranging between 330 bytes and 426 MB. This leads for the fact that flows of 1 MB may fall in any or both of the two groups. We decided next to use only flow duration as the stratification variable as we were unable to establish clear strata limits for flow sizes. Fig. 5 depicts the upper limits of the flow duration for 2, 4, 6 and 8 groups produced by CLARA and K-means, in a base 10 logarithmic scale. It can be observed that CLARA produces limits (except for the last group) approximately two magnitude levels lower than those obtained using Kmeans. This behavior is repeated throughout the four numbers of groups. In other words, K-means tends to put a high number of elements into the first stratum leaving fewer to the remaining strata. We will come back later to this point and show that it has a significant impact on the stratified results. In a traffic analysis tool, we may of course think of using this to adapt dynamically the limits between strata based on the current characteristics of the flow records, but in a time scale significantly higher than dealing with individual
5.3. Using stratification together with clustering In Section 5.1 we manually configured the limits between contiguous strata using our prior knowledge of traffic and work experience. As explained in Section 4, now we consider a different approach for setting up the limits of strata, i.e. using the upper limits identified by the cluster analysis of Section 5.2. Fig. 6 depicts the results for the mean of flow duration for 8 strata that are similar to those shown in Fig. 3. First we see that the stratified samples produced by CLARA and K-means are acceptable since all confidence intervals cover the population mean. More importantly and as expected, we see that CLARA outperforms K-means, i.e. that its limits produce more representative samples. This may be observed for precision (proximity of the population
Table 2 Lower and upper limits for 2 groups (Trace #1) Duration (s)
Size
CLARA
CLARA
K-means
Lower
Upper
Lower
Upper
Lower (B)
Upper (MB)
Lower (B)
Upper (MB)
0.0 155.0
155.0 83.8
0.0 3.3
3.3 83.8
23 56
24 426
23 330
115 426
5 1
4
2
3 2 1
Upper Limit (log10s)
Upper Limit (log10s)
5
0
4
1
3
2
2 3 1 4
0 CLARA
K-Means
CLARA
(a) 2 groups
K-Means
(b) 4 groups
5
Upper Limit (log10s)
1 2
K-means
5 1
4 2 3 3 2
4
1
5
0
6 CLARA
(c) 6 groups
K-Means
1
Upper Limit (log10s)
Group
4
2 3
3
4 2
5 6
1
7 0 CLARA
K-Means
(d) 8 groups
Fig. 5. Upper limits from the groups considering the flow duration (Trace #1).
8
2685
S. Fernandes et al. / Computer Networks 52 (2008) 2677–2689
17.3 population k-means clara
17.2 17.1 17.0 16.9 16.8
when: (a) using 8 strata for 0.01% sample sizes; (b) at least 6 strata for 0.1% and 1% sample sizes; and (c) for 10% sample sizes even 2 strata yield reliable results (although the advantage of using sampling is diminished). 5.4. Smart sampling We wanted to know next how our proposed sampling methodology did compare with smart sampling described in [5,10]. Fig. 8 shows how good each method estimates the mean of flow duration under different sample sizes. First, smart sampling was able to build even lower confidence intervals than CLARA (confidence intervals are not shown in Fig. 8 for the sake of improving the visual quality of the picture). This result was expected as it uses a sampling threshold that is automatically chosen for getting lower variability among elements within the sample. Second, as far as our experiments are concerned, smart sampling was not able to obtain estimates of the population mean as precise as stratified sampling. Mainly for sample sizes higher than 0.01%, CLARA obtained at least the same precision as smart. Comparing with K-means however, smart had a higher precision. We also saw that processing smart was a very CPU intensive task, actually several times slower than stratified sampling. For example, using a 3.2 GHz Pentium 4 station, smart sampling took a couple of hours for processing a 1% sample size experiment for one trace with 100 replications, whereas stratified sampling took only a few minutes to perform the same task. This turns smart sampling’s usage
Mean of flow duration (s)
Mean of flow duration (s)
mean) and for samples variability (size of the confidence interval). We saw earlier that the upper limit of the first group of K-means is almost two levels of magnitude higher than CLARA leading K-means to classifying more elements into the first group. For example, for eight groups on the Trace #1, CLARA yields an upper flow duration limit of 4.5 s and includes 5,005,776 flows, corresponding to 71.4% of the total number of flows in the trace. On the other hand, for Kmeans this limit is 156 s with as many as 6,863,446 flows, representing 97.9% of the flows therefore leading to a larger sample variance as longer flows are also included. Since higher strata (those with higher flow durations) have smaller sub-samples, the estimator for the mean of the stratified sampling will give a higher weight to these subsamples. The smaller sub-samples of flows with longer durations together with their higher weight make the estimator too much dependent on the specific elements taken from those strata for the sub-sample. Hence, the estimator for K-means computes less precise and more variable means than the one for CLARA. Our first conclusion is that the samples produced by K-means are less representative of the population, as confirmed by Fig. 6. Fig. 7 depicts the stratification results obtained with different number of strata (2, 4, 6 and 8) for CLARA, K-means and expo (manual assigned limits for strata). Please recall that the results presented in Fig. 6 refer to 8 strata, which represented the case with the most suitable number of strata we found. These results from Fig. 7 are also similar to those of Fig. 4, showing that adequate results are yielded
16.7
17.1 population k-means clara
17.0 16.9 16.8 16.7 16.6 16.5
0.01%
0.1%
1%
10%
0.01%
0.1%
1%
10%
Sample size
Sample size
(a) Trace #1
(b) Trace #2 population k-means clara
18.9 18.8 18.7 18.6 18.5 18.4 18.3 18.2
Mean of flow duration (s)
Mean of flow duration (s)
19.0 29.7
population k-means clara
29.5 29.3 29.1 28.9 28.7 28.5 28.3
0.01%
0.1%
1%
Sample size
(c) Trace #3
10%
0.01%
0.1%
1%
Sample size
(d) Trace #4
Fig. 6. Mean of flow duration for different traces (8 strata).
