Visual Studio Code is a code editor redefined and optimized for building and debugging modern web and cloud applications. Visual Studio Code is free and available on your favorite platform. To install any of them, just hit Ctrl-Shift-P (Windows) inside Visual Studio code, type inst, select Extensions: Install Extension, then type vim. All three will come up, along with a few other things which are not Vim emulators for VSCode. None of those extensions are flawless.

•••

I’ve been using vim for a while now, but the recent noise around Visual Studio Code had me curious, especially given some long-running frustrations with vim. I have a fairly comprehensive vim config, but it often feels fragile. vim-go, YouCompleteMe & ctags sit on top of vim to provide autocompletion: but re-compiling libraries, dealing with RPC issues and keeping it working when you just want to write code can be Not Fun. Adding proper autocompletion for additional languages—like Python and Ruby—is an exercise in patience (and spare time).

VS Code, on the other hand, is pretty polished out of the box: autocompletion is significantly more robust (and tooltips are richer), adding additional languages is extremely straightforward. If you write a lot of JavaScript/Babel or TypeScript, then it has some serious advantages (JS-family support is first-class). And despite the name, Visual Studio Code (“VS Code”) doesn’t bear much resemblance to Visual Studio proper. Instead, it’s most similar to GitHub’s Atom editor: more text editor than full-blown IDE, but with a rich extensions interface that allows you to turn it into an IDE depending on what language(s) you hack on.

Thus, I decided to run with VS Code for a month to see whether I could live with it. I’ve read articles by those switching from editors like Atom, but nothing on a hard-swap from vim. To do this properly, I went all in:

  • I aliased vim to code in my shell (bad habits and all that)
  • Changed my shell’s $EDITOR to code
  • Set git difftool to use code --wait --diff $LOCAL $REMOTE.

Note that I still used vim keybindings via VSCodeVim. I can’t imagine programming another way.

Notes

Worth noting before you read on:

  • When I say “vim” I specifically mean neovim: I hard-switched sometime late in 2015 (it was easy) and haven’t looked back.
  • I write a lot of Go, some Python, Bash & and ‘enough’ JavaScript (primarily Vue.js), so my thoughts are going to be colored by the workflows around these languages.
  • vim-go single-handedly gives vim a productivity advantage, but vscode-go isn’t too far behind. The open-godoc-in-a-vim-split (and generally better split usage) of vim-go is probably what wins out

Saying that, the autocompletion in vscode-go is richer and clearer, thanks to VS Code’s better autocompletion as-a-whole, and will get better.

Workflow

Throughout this period, I realised I had two distinct ways of using an editor, each prioritizing different things:

  • Short, quick edits. Has to launch fast. This is typically anything that uses $EDITOR (git commit/rebase), short scripts, and quickly manipulating data (visual block mode + regex work well for this).
  • Whole projects. Must manage editing/creating multiple files, provide Git integration, debugging across library boundaries, and running tests.

Lots of overlap, but it should be obvious where I care about launch speed vs. file management vs. deeper language support.

Short Edits

Observations:

Code
  • VS Code’s startup speed isn’t icicle-like (think: early Atom), but it’s still slow, especially from a cold-start. ~5 seconds from code $filename to a text-rendered-and-extensions-loaded usable, which is about twice that of a plugin-laden neovim.
  • Actual in-editor performance is good: command responsiveness, changing tabs, and jumping to declarations never feels slow.
  • If you’ve started in the shell, switching to another application to edit a file or modify a multi-line shell command can feel a little clunky. I’d typically handle this by opening a new tmux split (retaining a prompt where I needed it) and then using vim to edit what I needed.

Vim In Visual Studio Code

Despite these things, it’s still capable of these tasks. vim just had a huge head-start, and is most at home in a terminal-based environment.

Whole Projects

VS Code is really good here, and I think whole-project workflows are its strength, but it’s not perfect.

  • The built-in Git support rivals vim-fugitive, moving between splits/buffers is fast, and it’s easy enough to hide. The default side-by-side diffs look good, although you don’t have as many tools to do a 3-way merge (via :bufget, etc) as you do with vim-fugitive.
  • Find-in-files is quick, although I miss some of the power of ag.vim, which hooks into my favorite grep replacement, the-silver-searcher.
  • What I miss from NERDTree is the ability to search it just like a buffer: /filename is incredibly useful on larger projects with more complex directory structures (looking at you, JS frameworks!). You’re also not able to navigate the filesystem up from the directory you opened, although I did see an issue for this and a plan for improvement.

I should note that opening a directory in VS Code triggers a full reload, which can be a little disruptive.

Free

Other Things

There’s a bunch of smaller things that, whilst unimportant in the scope of getting things done, are still noticeable:

  • Font rendering. If you’re on macOS (nee OS X), then you’ll notice that VS Code’s font rendering (Chromium’s font rendering) is a little different from your regular terminal or other applications. Not worse; just different.
  • Tab switching: good! Fast, and there’s support for vim commands like :vsp to open files in splits.
  • You can use most of vim’s substitution syntax: :s/before/after/(g) works as expected. gc (for confirmation) doesn’t appear to work.
  • EasyMotion support is included in the VSCodeVim plugin: although I’m a vim-sneak user, EasyMotion is arguably more popular among vim users and serves the same overall goals (navigating short to medium distances quickly). <leader><leader>f<char> (in my config) allows me to easily search forwards by character.
  • The native terminal needs a bunch of work to make me happy. It’s based on xterm.js, which could do with a lot more love if VS Code is going to tie itself to it. It just landed support for hyperlinks (in VS Code 1.9), but solid tmux support is still lacking and makes spending time in the terminal feel like a chore vs. iTerm.
  • Configuration: I aliased keybindings.json and settings.json into my dotfiles repository, so I can effectively sync them across machines like .vimrc. Beyond that: VS Code is highly configurable, and although writing out JSON can be tedious, it does a lot to make changing default settings as easy as possible for you (autocompletion of settings is a nice touch).

You might also be asking: what about connecting to other machines remotely, where you only have an unadorned vim on the remote machine? That wasn’t a problem with vim thanks to the netrw plugin—you would connect to/browse the remote filesystem with your local, customized vim install—but is a shortcoming with VS Code. I wasn’t able to find a robust extension that would let me do this, although (in my case) it’s increasingly rare to SSH into a box given how software is deployed now. Still, worth keeping in mind if vim scp://[email protected]:/path/to/script.sh is part of your regular workflow.

So, Which Editor?

I like VS Code a lot. Many of the things that frustate me are things that can be fixed, although I suspect improving startup speed will be tough (loading a browser engine underneath and all). Had I tried it 6+ months ago it’s likely I would have stuck with vim. Now, the decision is much harder.

I’m going to stick it out, because for the language I write the most (Go), the excellent autocompletion and toolchain integration beat out the other parts. If you are seeking a modern editor with 1:1 feature parity with vim, then look elsewhere: each editor brings its own things to the table, and you’ll never be pleased if you’re seeking that.

Posted on 15 February 2017

Neovim integration for Visual Studio Code

For those who don't know Neovim is the fork of VIM to allow greater VIM extensibility and embeddability. The extension is using full embedded neovim instance as backend (with the exception of the insert mode and window/buffer/file management), no more half-complete VIM emulation

Please report any issues/suggestions to vscode-neovim repository

Installation

  • Install vscode-neovim extension
  • Install Neovim Required version 0.5.0 nightly or greater
    • Tip: You can install neovim-0.5.0-nightly separately for just vscode, outside of your system's package manager installation
  • Set neovim path in the extension settings and you're good to go.
    • Important you must specify full path to neovim, like C:Neovimbinnvim.exe or /usr/local/bin/nvim.
    • IMPORTANT 2: the setting id is vscode-neovim.neovimExecutablePaths.win32/linux/darwin
  • Important!: If you already have big & custom init.vim i'd recommend to wrap existing settings & plugins with if !exists('g:vscode') check to prevent potential breakings and problems. If you have any problems - try with empty init.vim first

Neovim 0.5+ is required. Any version lower than that won't work. Many linux distributions have an old version of neovim in their package repo - always check what version are you installing.

If you get Unable to init vscode-neovim: command 'type' already exists message, try to uninstall other VSCode extensions, which register type command (i.e. VSCodeVim or Overtype).

WSL

If you want to use WSL version of neovim, set useWSL configuration toggle and specify linux path to nvim binary. wsl.exe windows binary and wslpath linux binary are required for this. wslpath must be available through $PATH linux env setting. Use wsl --list to check for the correct default linux distribution.

Features

  • Almost fully feature-complete VIM integration by utilizing neovim
  • First-class VSCode insert mode. The plugin unbinds self from the type event in the insert mode, so no typing lag and freezing anymore when long completion popup appears.
  • Fully working VSCode features - autocompletion/go to definition/snippets/multiple cursors/etc..
  • vimrc/vim plugins/etc are supported (few plugins don't make sense with vscode, such as nerdtree)

Requirements

Neovim 0.5.0-nightly or greater

Important

  • Visual modes are not producing real vscode selections (few versions had this feature previously, but it was implemented through ugly & hacky workarounds). Any vscode commands expecting selection won't work. To round the corners, invoking VSCode command picker through the default hotkeys (f1/ctrl/cmd+shift+p) from visual mode converts vim selection to real vscode selection. Also commenting/indenting/formatting works out of the box too. If you're using some custom mapping for calling vscode commands and depends on real vscode selection, you can use VSCodeNotifyRange/VSCodeNotifyRangePos (the first one linewise, the latter characterwise) functions which will convert visual mode selection to vscode selection before calling the command. See this for example and mapping
  • The extension for now works best if editor.scrollBeyondLastLine is disabled.
  • When you type some commands they may be substituted for the another, like :write will be replaced by :Write. This is normal.
  • File/tab/window management (:w/q/etc..) commands are substituted and mapped to vscode actions. If you're using some custom commands/custom mappings to them, you might need to rebind them to call vscode actions instead. See reference links below for examples if you want to use custom keybindings/commands. DO NOT use vim :w, etc.. in scripts/keybindings, they won't work.
  • On a Mac, the h, j, k and l movement keys may not repeat when held, to fix this open Terminal and execute the following command:defaults write com.microsoft.VSCode ApplePressAndHoldEnabled -bool false

VSCode specific features and differences

  • =, are mapped to editor.action.formatSelection
  • It's possible to call vscode commands from neovim. See VSCodeCall/VSCodeNotify vim functions in vscode-neovim.vim file. VSCodeCall is blocking request, while VSCodeNotify is not (see below)
  • Scrolling is done by VSCode side. <C-d>/<C-u>/etc.. are slightly different
  • File management commands such as e / w / q etc are mapped to corresponding vscode commands and behavior may be different (see below)
  • gd/<C-] are mapped to editor.action.revealDefinition (Shortcut F12), also <C-]> works in vim help files
  • gf is mapped to editor.action.revealDeclaration
  • gH is mapped to editor.action.referenceSearch.trigger
  • gD/gF are mapped to editor.action.peekDefinition and editor.action.peekDeclaration respectively (opens in peek)
  • <C-w>gd/<C-w>gf are mapped to editor.action.revealDefinitionAside (original vim command - open new tab and go to the file under cursor, but vscode/vim window/tabs metaphors are completely different, so it's useful to do slightly different thing here)
  • gh is mapped to editor.action.showHover
  • Dot-repeat (.) . Works starting from 0.0.52 version. Moving cursor within a change range won't break the repeat sequence. I.e. in neovim, if you type abc<cursor> in insert mode then move cursor to a<cursor>bc and type 1 here the repeat sequence would be 1. However in vscode it would be a1bc. Another difference that . repeat command when you delete some text only works from right-to-left. I.e. it will treat <Del> key as <BS> keys for dot repeat.

Performance/Latency problems

If you have any performance problems (cursor jitter usually) make sure you're not using these kinds of extensions:

  • Line number extensions (VSCode has built-in support for normal/relative line numbers)
  • Indent guide extensions (VSCode has built-in indent guides)
  • Brackets highlighter extensions (VSCode has built-in feature)
  • Anything that renders decorators/put something into vscode gutter very often, e.g. on each cursor/line move

Such extension may be fine and work well, but combined with any extension which should control the cursor position (such as any vim extension) it may work very bad, due to shared vscode extension host between all extensions (E.g. one extension is taking the control over the host and blocking the other extension, this produces jitter).

If you're not sure, disable all other extensions except mine, reload vscode/window and see if the problem persist before reporting.

Also there are a reports that some vim settings/vim plugins increase latency and causing performance problems. Make sure you've disabled unneeded plugins. Many of them don't make sense with vscode and may cause any sort of problems. You don't need any code, highlighting, completion, lsp plugins as well any plugins that spawn windows/buffers (nerdtree and similar), fuzzy-finders plugins, etc. You might want to keep navigation/text-objects/text-editing/etc plugins - they should be fine.

Enabling jj or jk as escape keys from the insert mode

Put into your keybindings.json:

for jj

Visual Studio Code Vim Tabs

to enable jk add also:

Determining if running in vscode in your init.vim

This should do the trick:

Invoking vscode actions from neovim

There are few helper functions that could be used to invoke any vscode commands:

  • VSCodeNotify(command, ..)/VSCodeCall(command, ..) - invokes vscode command with optional arguments
  • VSCodeNotifyRange(command, line1, line2, leaveSelection ,..)/VSCodeCallRange(command, line1, line2, leaveSelection, ..) - produces real vscode selection from line1 to line2 and invokes vscode command. Linewise. Put 1 for leaveSelection argument to leave vscode selection after invoking the command
  • VSCodeNotifyRangePos(command, line1, line2, pos1, pos2, leaveSelection ,..)/VSCodeCallRangePos(command, line1, line2, pos1, pos2, leaveSelection, ..) - produces real vscode selection from line1.pos1 to line2.pos2 and invokes vscode command. Characterwise

Functions with Notify in name are non-blocking, the ones with Call are blocking. Generally use Notify unless you really need a blocking call

Examples:

Produce linewise selection and show vscode commands (default binding)

Produce characterwise selection and show vscode commands (default binding):

Run Find in files for word under cursor in vscode:

Open definition aside (default binding):

Jumplist

VSCode's jumplist is being used. Make sure to bind to workbench.action.navigateBack / workbench.action.navigateForward if you're using custom mappings. Marks (both upper & lowercased) should be fine

Wildmenu completion

Command menu has the wildmenu completion on type. The completion options appear after 1.5s (to not bother you when you write :w or :noh). <Up>/<Down> selects the option and <Tab> accepts it. See the gif:

Multiple cursors

Multiple cursors work in:

  1. Insert mode
  2. (Optional) Visual line mode
  3. (Optional) Visual block mode

To spawn multiple cursors from visual line/block modes type ma/mA or mi/mI (by default). The effect differs:

  • For visual line mode mi will start insert mode on each selected line on the first non whitespace character and ma will on the end of line
  • For visual block mode mi will start insert on each selected line before the cursor block and ma after
  • mA/mI versions account empty lines too (only for visual line mode, for visual block mode they're same as ma/mi)

See gif in action:

Custom keymaps for scrolling/window/tab/etc.. management

  • See vscode-scrolling.vim for scrolling commands reference
  • See vscode-file-commands.vim for file commands reference
  • See vscode-tab-commands.vim for tab commands reference
  • See vscode-window-commands.vim for window commands reference

File/Tab management commands

:e[dit] or ex

  • :e without argument and without bang (!) - opens quickopen window
  • :e! without argument and with bang - opens open file dialog
  • :e [filename] , e.g. :e $MYVIMRC - opens a file in new tab. The file must exist
  • :e! [filename], e.g. :e! $MYVIMRC - closes current file (discard any changes) and opens a file. The file must exist

ene[w]

  • enew Creates new untitled document in vscode
  • enew! closes current file (discard any changes) and creates new untitled document

fin[d]

  • Opens vscode's quick open window. Arguments and count are not supported

w[rite]

  • Without bang (!) saves current file
  • With bang opens 'save as' dialog

sav[eas]

  • Opens 'save as' dialog

wa[ll]

  • Saves all files. Bang is not doing anything

q[uit] or keys <C-w> q / <C-w> c

  • Closes the active editor

wq

  • Saves and closes the active editor

qa[ll]

  • Closes all editors, but doesn't quit vscode. Acts like qall!, so beware for a nonsaved changes

wqa[ll]/xa[ll]

  • Saves all editors & close

tabe[dit]

  • Similar to e[dit]. Without argument opens quickopen, with argument opens the file in new tab

tabnew

  • Opens new untitled file

tabf[ind]

  • Opens quickopen window

tab/tabs

  • Not supported. Doesn't make sense with vscode

tabc[lose]

  • Closes active editor (tab)

tabo[nly]

  • Closes other tabs in vscode group (pane). This differs from vim where a tab is a like a new window, but doesn't make sense in vscode.

tabn[ext] or key gt

  • Switches to next (or count tabs if argument is given) in the active vscode group (pane)

tabp[revious] or key gT

  • Switches to previous (or count tabs if argument is given) in the active vscode group (pane)

tabfir[st]

  • Switches to the first tab in the active editor group

tabl[ast]

  • Switches to the last tab in the active edtior group

tabm[ove]

  • Not supported yet

Keys ZZ and ZQ are bound to :wq and q! respectively

Buffer/window management commands

Note: split size distribution is controlled by workbench.editor.splitSizing setting. By default it's distribute, which is mapped to vim's equalalways and eadirection = 'both' (default)

sp[lit] or key <C-w> s

  • Split editor horizontally. When argument given opens the specified file in the argument, e.g :sp $MYVIMRC. File must exist

vs[plit] or key <C-w> v

  • Split editor vertically. When argument given opens the specified file in the argument. File must exist

new or key <C-w> n

  • Like sp[lit] but creates new untitled file if no argument given

vne[w]

  • Like vs[plit] but creates new untitled file if no argument given

<C-w> ^

  • Not supported yet

vert[ical]/lefta[bove]/etc..

  • Not supported yet

on[ly] or key <C-w> o

  • Without bang (!) Merges all editor groups into the one. Doesn't close editors
  • With bang closes all editors from all groups except current one

<C-w> j/k/h/l

  • Focus group below/above/left/right

<C-w> <C-j>/<C-i>/<C-h>/<C-l>

  • Move editor to group below/above/left/right. Vim doesn't have analogue mappings. Note: <C-w> <C-i> moves editor up. Logically it should be <C-w> <C-k> but vscode has many commands mapped to <C-k> [key] and doesn't allow to use <C-w> <C-k> without unbinding them first

<C-w> r/R/x

  • Not supported use <C-w> <C-j> and similar to move editors

<C-w> w or <C-w> <C-w>

  • Focus next group. The behavior may differ than in vim

Visual Studio Code Vim Plugin

<C-w> W or <C-w> p

  • Focus previous group. The behavior may differ than in vim. <C-w> p is completely different than in vim

<C-w> t

  • Focus first editor group (most top-left)

<C-w> b

  • Focus last editor group (most bottom-right)

<C-w> H/K/J/L

  • Not supported yet

<C-w> =

  • Align all editors to have the same width

[count]<C-w> +

  • Increase editor height by (optional) count

[count]<C-w> -

  • Decrease editor height by (optional) count

[count]<C-w> >

  • Increase editor width by (optional) count

[count]<C-w> <

  • Decrease editor width by (optional) count

To use VSCode command 'Increase/decrease current view size'

  • workbench.action.increaseViewSize

  • workbench.action.decreaseViewSize

    Copy this into init.vim

<C-w> _

  • Toggle maximized editor size. Pressing again will restore the size

Insert mode special keys

Enabled by useCtrlKeysForInsertMode = true (default true)

KeyDescStatus
CTRL-r [0-9a-z'%#*+:.-=]Paste from registerWorks
CTRL-aPaste previous inserted contentWorks
CTRL-uDelete all text till begining of line, if empty - delete newlineBound to VSCode key
CTRL-wDelete word leftBound to VSCode key
CTRL-hDelete character leftBound to VSCode key
CTRL-tIndent lines rightBound to VSCode indent line
CTRL-dIndent lines leftBound to VSCode outindent line
CTRL-jInsert lineBound to VSCode insert line after

Other keys are not supported in insert mode

Normal mode control keys

Enabled by useCtrlKeysForNormalMode = true (default true)

Refer to vim manual to get help what they're doing

  • CTRL-a
  • CTRL-b
  • CTRL-c
  • CTRL-d
  • CTRL-e
  • CTRL-f
  • CTRL-i
  • CTRL-o (see https://github.com/asvetliakov/vscode-neovim/issues/181#issuecomment-585264621)
  • CTRL-r
  • CTRL-u
  • CTRL-v
  • CTRL-w
  • CTRL-x
  • CTRL-y
  • CTRL-]
  • CTRL-j
  • CTRL-k
  • CTRL-l
  • CTRL-h
  • CTRL-/

Other control keys are not being sent (Usually useless with vscode)

Cmdline control keys (always enabled)

  • CTRL-h (delete one character left)
  • CTRL-w (delete word left)
  • CTRL-u (clear line)
  • CTRL-g / CTRL-t (in incsearch mode moves to next/previous result)
  • CTRL-l (add next character under the cursor to incsearch)
  • CTRL-n / CTRL-p (go down/up history)
  • <Up>/<Down> (Select next/prev suggestion) (no way to make up/down to navigate through history, vscode disallows remapping)
  • Tab - Select suggestion

Pass additional keys to neovim or disable existing ctrl keys mappings

To pass additional ctrl key sequence, for example add to your keybindings.json:

Visual Studio Code Vi Mode

To disable existing ctrl key sequence, for example Ctrl+A add to your keybindings.json

Vim Like Visual Studio Code

Vim-easymotion

Speaking honestly, original vim-easymotion works fine and as expected.. except one thing: it really replaces your text with markers then restores back. It may work for VIM but for VS Code it leads to broken text and many errors reported while you're jumping. For this reason I created the special vim-easymotion fork which doesn't touch your text and instead use vscode text decorations. Just add my fork to your vim-plug block or by using your favorite vim plugin installer and delete original vim-easymotion. Also overwin motions won't work (obviously) so don't use them. Happy jumping!

Vim-commentary

You can use vim-commentary if you like it. But vscode already has such functionality so why don't use it? Add to your init.vim/init.nvim

Similar to vim-commentary, gcc is comment line (accept count), use gc with motion/in visual mode. VSCodeCommentary is just a simple function which calls editor.action.commentLine

VIM quick-scope

quick-scope plugin uses default vim HL groups by default but they are normally ignored. To fix add

to your init.vim

Vim Shortcuts Visual Studio Code

Known Issues

Vim Visual Studio Code Color Scheme

See Issues section

How it works

  • VScode connects to neovim instance
  • When opening a some file, a scratch buffer is created in nvim and being init with text content from vscode
  • Normal/visual mode commands are being sent directly to neovim. The extension listens for buffer events and applies edits from neovim
  • When entering the insert mode, the extensions stops listen for keystroke events and delegates typing mode to vscode (no neovim communication is being performed here)
  • After pressing escape key from the insert mode, extension sends changes obtained from the insert mode to neovim

Credits & External Resources

  • vim-altercmd - Used for rebinding default commands to call vscode command
  • neovim nodejs client - NodeJS library for communicating with Neovim
